Mini 4-channel Amplifier

Quality Sound in Tight Spaces

Specs:

link500.4mini Features

• 500 Watt 4-Channel Amplifier

• 75 watts x 4 @ 4 ohms

• 125 watts x 4 @ 2 ohms

• 250 watts x 2 @ 4 ohms BTL

  • Small Footprint Only 9.2”x4.5”x1.65”

  • Adjustable Paragraphic EQ (Channels 3/4)

  • Variable Subsonic Filter (Channels 3/4)

  • Variable Hi/Low Pass Crossover (-12dB/oct)

• Remote Level Control (RLC) w/Optional linkRC (CH 3/4)

• Built-In Summing w/Level Trim Adjustment

• Parametric EQ (CH 3/4)

• Active Thermal Management

• Start/Stop System Compatible

• Adaptive OEM Load Technology

• 40V Input Capability

• Differential Balanced Inputs

• Variable Gain Adjustment w/Clip LED

• Auto Turn-On via DC-Offset or Audio Signal Detect

• Locking Detachable Hi-Level Speaker Terminals

• Professional Grade Panel Mount RCA’s

• Compact Aluminum Chassis w/Detachable Mounting tabs

lin500.4mini Specifications

• Input Sensitivity

  • SPK --------------------------- 1-20Vrms, 2-40Vrms

  • RCA --------------------------- 0.2V-5Vrms, 0.4V-10Vrms

• Max Input Voltage (SPK) ------ 40Vrms

• Frequency Response ----------- <10Hz to >43kHz (+0/-3dB)

• THD+N ------------------------------- <1% at rated power

• S/N ------------------------------------- >78dBA (1W, 4Ω)
