Wavtech Link700.4plus 4-channel Amplifier
Specs:
link700.4plus Features
-
700 Watt 4-Channel Amplifier
-
100 watts x 4 @ 4 ohms
-
175 watts x 4 @ 2 ohms
-
350 watts x 2 @ 4 ohms BTL
-
Small Footprint Only 10.25”x5.5”x1.65”
-
Variable HP Crossover (-12dB/oct) with 1x/10x CH1/2
-
Variable HP/BP/LP Crossover (-12dB/oct) CH3/4
-
Variable LP Crossover (-24dB/oct) RCA Pre-Out
-
Variable Subsonic Filter (-24dB/oct) RCA Pre-Out
-
Adjustable Parametric EQ RCA Pre-Out
-
-
Remote Level Control (RLC) w/Optional linkRC (Channels 3/4 or RCA Pre-Out)
-
bassFREQ Bass Processor w/Parametic EQ (CH 3/4 or Pre-Out)
-
Active Thermal Management
-
Start/Stop System Compatible
-
Adaptive OEM Load Technology
-
40V Input Capability
-
Differential Balanced Inputs
-
Variable Gain Adjustment w/Clip LED
-
Auto Turn-On via DC-Offset or Audio Signal Detect
-
Locking Detachable Hi-Level Speaker Terminals
-
4 Gauge Power/Ground Terminals
-
Professional Grade Panel Mount RCA’s
-
Compact Aluminum Chassis w/Detachable Mounting tabs
link700.4plus Specifications
-
Input Sensitivity
-
SPK --------------------------- 1-20Vrms, 2-40Vrms
-
RCA --------------------------- 0.2V-5Vrms, 0.4V-10Vrms
-
-
Max Input Voltage (SPK) ------ 40Vrms
-
Frequency Response ----------- <10Hz to >45kHz (+0/-3dB)
-
THD+N ------------------------------- <1% at rated power
-
S/N ------------------------------------- >80dBA (1W, 4Ω)
