Diamond Audio DXM600.2D 2-Channel Waterproof Full Range Amplifier 600W RMS

TYPE: Amplifiers
VENDOR: Diamond Audio
  • DXM600.2D DXM Series 2-Channel 600W RMS Full Range Class D Waterproof Amplifier
  • DXM600.2D DXM Series 2-Channel 600W RMS Full Range Class D Waterproof Amplifier
  • DXM600.2D DXM Series 2-Channel 600W RMS Full Range Class D Waterproof Amplifier
  • DXM600.2D DXM Series 2-Channel 600W RMS Full Range Class D Waterproof Amplifier
1 4

PRODUCT INFORMATION

Diamond Audio DXM600.2D 2-Channel Waterproof Full Range Amplifier 600W RMS

TYPE: Amplifiers
VENDOR: Diamond Audio
Type: Amplifiers
Vendor: Diamond Audio

$529.99

$629.99

$529.99

Sale Sold out
Tax included. Shipping calculated at checkout.

Additional Payment Info

Frame_8859
unnamed
ShopPay
View full details
Motorcycle Audio

Diamond Audio DXM600.2D 2-Channel Waterproof Full Range Amplifier 600W RMS

Need Help?

Call us at (864) 334‑6131 or message our team with your bike year/model and current upgrades. We'll map the best path to louder, cleaner sound.

  • Description

  • Reviews

Diamond Audio - DXM600.2D

DXM Series 2-Channel 600W RMS Full Range Class D Waterproof Amplifier

All weather amplifier for your OUTDOOR life (IPX67 Rated)

Specifications

Ratings:
  • Power @ 2Ω: 300W RMS x 2
  • Power @ 4Ω: 200W RMS x 2
  • Power @ 4Ω Bridged: 600W RMS x 1
  • Total Harmonic Distortion: <0.3%
  • S/N Ratio (1W@4Ω): >-102dB
  • Gain Range: 0.2v-10v
  • Crossover Range: 40Hz-400Hz
  • Frequency Range: 10Hz-33KHz
  • Bass Boost: 0dB-18dB
  • Current Draw Full Power(Music): 70A (7A) AVG
  • Fuse Rating: 35A
  • Dimensions: 9.5”x4.3”x1.7” (241.6mm x 110mm x 44.0mm)
Features
  • Power & Protection Led Light Status Indicator
  • Short Circuit, Thermal and Voltage Protection
  • Selectable X-Over: LPF/FULL/HPF
  • IPX67 Rated

DXM Series Amplifier Manual
DXM600.2D One Sheet
