Cicada Audio 24FLXPCM-4X8RG 1400W DSP 8-Speaker System for 2024+ Road Glide
PRODUCT INFORMATION
Cicada Audio 24FLXPCM-4X8RG 1400W DSP 8-Speaker System for 2024+ Road Glide
$4,299.99
Couldn't load pickup availability
Additional Payment Info
Cicada Audio 24FLXPCM-4X8RG 1400W DSP 8-Speaker System for 2024+ Road Glide
Need Help?
Call us at (864) 334‑6131 or message our team with your bike year/model and current upgrades. We'll map the best path to louder, cleaner sound.
-
Description
-
Reviews
Cicada Audio 24FLXPCM-4X8RG 1400W DSP 8-Speaker System
Build a complete high-output component audio system in a compatible 2024 and newer Harley-Davidson Road Glide with four mid-bass drivers, four shallow horn tweeters, integrated DSP tuning and direct factory A2B signal integration.
The package creates a matched front and rear system with 6.5-inch component speakers in the Road Glide fairing and 6×9 component speakers in the saddlebag lids. Road Glide grilles, tweeter bridges, lid hardware, amplifier mounting, power wiring and rear-speaker wiring are included.
Eight-Driver Road Glide System
- Designed for compatible 2024+ Road Glide motorcycles
- FLX1400.4PRO amplifier with six-channel DSP
- 225 watts RMS × 4 at 4 ohms
- 350 watts RMS × 4 at 2 ohms
- Two CM65.2X 6.5-inch front mid-bass drivers
- Two RR075T front fairing tweeters
- Two CM69.2X 6×9 rear mid-bass drivers
- Two RR075T rear saddlebag tweeters
- Road Glide tweeter grilles included
- Rear tweeter bridges included
- 2024+ saddlebag lid cut-in system included
- NAV-TV ZEN-H A2B integration included
- Road Glide amplifier rack included
24FLXPCM-4X8RG Complete System Overview
The Cicada Audio 24FLXPCM-4X8RG combines the primary audio, DSP, integration, wiring and mounting components required for a complete eight-driver Road Glide audio system.
The front system uses two CM65.2X 6.5-inch mid-bass drivers and two RR075T shallow horn tweeters mounted in Road Glide-specific fairing grilles. The rear system uses two CM69.2X 6×9 mid-bass drivers and two additional RR075T tweeters mounted above the rear drivers with the supplied saddlebag tweeter bridges.
The FLX1400.4PRO supplies four amplified DSP channels. Each front or rear component position combines one mid-bass driver and one tweeter through the applicable passive crossover network.
Eight-Speaker Component Layout
Front Road Glide Fairing
- Two CM65.2X 6.5-inch mid-bass drivers
- Two RR075T shallow horn tweeters
- Two Road Glide tweeter grilles
- One left and one right component channel
Rear Saddlebag Lids
- Two CM69.2X 6×9 mid-bass drivers
- Two RR075T shallow horn tweeters
- Two 24CHD69TB tweeter bridges
- One left and one right component channel
Everything Included in the Complete System
FLX1400.4PRO DSP Amplifier
One four-channel Class-D amplifier with four amplified DSP channels, two processed pass-through outputs, Bluetooth audio streaming and USB-C computer tuning.
24CHDRGGTK-075 Front Grilles
One matched pair of Road Glide-specific powder-coated metal grilles with mounted RR075T shallow horn tweeters and passive crossover networks.
CM65.2X Front Mid-Bass Pair
Two 2-ohm 6.5-inch Carbon Matrix Composite mid-bass drivers for the Road Glide front fairing.
RR075T Rear Tweeter Pair
Two additional 4-ohm shallow ring-radiator horn tweeters for the saddlebag component system.
CM69.2X Rear Mid-Bass Pair
Two 2-ohm 6×9-inch Carbon Matrix Composite mid-bass drivers for the saddlebag lid locations.
24CHDLID Saddlebag Lid Kit
Complete top-load cut-in mounting system with angled 6×9 baffles, steel grilles, clamping rings, gaskets, templates, tethers and rain covers.
24CHD69TB Tweeter Bridges
One pair of rear 6×9 tweeter bridges designed to mount the RR075T tweeters above the saddlebag mid-bass drivers.
HDPG4K 4-AWG Power Kit
Heavy-gauge power and ground wiring, remote-turn-on wiring, fuse protection and amplifier-side terminations.
24HDZENHCAKIT A2B Interface
NAV-TV ZEN-H factory A2B interface with a Cicada Audio direct-connect harness and locking Molex connections.
24HDRO Rear-Output Harness
Plug-and-play rear-speaker harness with factory-style connectors and extended leads for routing audio into both saddlebags.
24HDAR-RG Amplifier Rack
Black-anodized aluminum Road Glide rack designed for compatible OEM amplifier mounting locations and Cicada FLX amplifiers.
FLX1400.4PRO Six-Channel DSP Amplifier
The FLX1400.4PRO combines a high-power four-channel Class-D amplifier with six channels of digital signal processing. Four DSP channels feed the internal amplifier while two processed outputs remain available for compatible future expansion.
225W × 4 at 4Ω
Published four-channel output for compatible 4-ohm speaker configurations.
350W × 4 at 2Ω
High-output capability for properly configured 2-ohm component systems.
700W × 2 Bridged
Published bridged output into compatible 4-ohm loads.
Six DSP Channels
Four amplified and two pass-through DSP channels support precise system control and expansion.
Bluetooth Streaming
Built-in Bluetooth audio streaming supports compatible playback, testing and system setup.
USB-C DSP Tuning
USB-C connectivity supports PC-based DIALD DSP configuration.
CM65.2X Front Mid-Bass Drivers
The CM65.2X pair uses lightweight Carbon Matrix Composite cones, neodymium motors and die-cast aluminum baskets to produce strong, efficient front-fairing mid-bass and vocal output.
CM69.2X Rear Mid-Bass Drivers
The CM69.2X pair creates the rear mid-bass foundation from the saddlebag lids. Each driver uses the same Carbon Matrix Composite cone technology, neodymium motor and high-temperature voice-coil design as the front pair.
RR075T Front and Rear Tweeters
Four RR075T shallow horn tweeters provide the system’s high-frequency output. Two are mounted in the Road Glide front grilles, while two are mounted over the rear 6×9 drivers using the supplied tweeter bridges.
Road Glide Front Grilles and Tweeter Integration
The 24CHDRGGTK-075 assembly uses Road Glide-specific kidney grilles with dedicated RR075T tweeter mounting. The matched pair preserves a clean, factory-style appearance while positioning the tweeters for strong forward projection.
- Designed for compatible 2024+ Road Glide fairings
- Powder-coated metal grille construction
- Matched left and right pair
- Integrated RR075T tweeter mounting
- External 12dB passive crossovers
- Replaceable tweeter diaphragms
- Low-profile fairing installation
24CHDLID Rear Component Installation
The included 24CHDLID system converts compatible 2024 and newer factory Harley-Davidson saddlebag lids into top-load 6×9 speaker locations. The 24CHD69TB bridges position the rear RR075T tweeters above the CM69.2X mid-bass drivers.
Top-Load 6×9 Baffles
Angled baffles direct the rear mid-bass output toward the rider.
Rear Tweeter Bridges
Dedicated bridges support clean RR075T placement over each rear mid-bass driver.
Steel Speaker Grilles
Powder-coated steel mesh protects the rear component assemblies.
Waterproof Gaskets
Clamping rings and gasket seals help protect the completed lid openings.
Precision Templates
Molded left and right templates support accurate lid cutting.
Rain Covers and Tethers
Rain covers, lid tethers and crossover-storage pouches are included.
NAV-TV A2B Signal Integration
The included 24HDZENHCAKIT uses the NAV-TV ZEN-H to integrate the compatible factory Harley-Davidson A2B audio signal with the Cicada amplifier.
- Direct-fit integration for compatible 2024+ A2B systems
- No cutting or splicing of the factory signal harness
- Correctly pinned Molex amplifier connections
- Automotive-grade materials
- Positive-locking connectors
- Compact routing inside the Road Glide fairing
- Stable signal delivery into the DSP amplifier
Power Wiring, Rear Harness and Amplifier Rack
HDPG4K Power Kit
Supplies the 4-AWG power and ground wiring required by the FLX1400.4PRO amplifier.
24HDRO Rear Harness
Provides factory-style connectors, extensions and color-coded wiring for both saddlebag component channels.
24HDAR-RG Rack
Uses compatible OEM Road Glide amplifier mounting locations and predrilled FLX amplifier holes.
DSP Setup and Component Protection
The front and rear mid-bass drivers, four tweeters, passive crossovers and high-power amplifier require careful DSP configuration.
- Follow the supplied component crossover wiring exactly.
- Do not connect the tweeters directly to full-range amplifier output.
- Configure independent front and rear high-pass filtering.
- Set amplifier output using measured clean voltage.
- Use DSP limiting to protect the mid-bass drivers and tweeters.
- Use equalization to balance fairing and saddlebag response.
- Use time alignment to improve front-to-rear arrival timing.
- Confirm left and right polarity before final assembly.
- Reduce output immediately if distortion or mechanical noise occurs.
Complete System Specifications
Fitment and Ordering Notes
- Designed for compatible 2024 and newer Road Glide motorcycles.
- The package includes eight individual audio drivers.
- Four mid-bass drivers and four tweeters are included.
- The mid-bass drivers are 2 ohms.
- The RR075T tweeters are 4 ohms.
- Use the supplied passive crossover networks.
- The FLX1400.4PRO provides the system DSP processing.
- The included ZEN-H is the non-DSP A2B interface.
- Road Glide front tweeter grilles are included.
- Rear tweeter bridges are included.
- Both compatible factory saddlebag lids require permanent cutting.
- Professional installation and DSP tuning are strongly recommended.
Best For
- Compatible 2024+ Road Glide complete audio upgrades
- Riders wanting front and rear component speakers
- Factory A2B systems requiring aftermarket integration
- High-output mid-bass and horn-tweeter systems
- Road Glide fairing and saddlebag audio builds
- Systems requiring built-in DSP tuning and output control
- Professional Road Glide audio installations
Related Motorcycle Audio Categories
Cicada and 2024+ Harley Audio
Amplifier and Signal Support
Cicada 24FLXPCM-4X8RG FAQ
How many speakers are included?
The system includes eight individual drivers: two front mid-bass drivers, two front tweeters, two rear mid-bass drivers and two rear tweeters.
Does the system require eight amplifier channels?
No. The eight drivers are arranged as four component channels. Each channel combines one mid-bass driver and one tweeter through the applicable passive crossover.
What impedance are the mid-bass drivers?
Each CM65.2X and CM69.2X mid-bass driver has a nominal impedance of 2 ohms.
What impedance are the tweeters?
Each RR075T tweeter has a nominal impedance of 4 ohms.
Can the driver impedances simply be connected in parallel?
No. Use the supplied passive crossover configuration and Cicada’s approved system wiring. Do not calculate the amplifier load by simply paralleling the raw mid-bass and tweeter impedances.
How much power does the amplifier produce?
The FLX1400.4PRO produces 225 watts RMS × 4 at 4 ohms, 350 watts RMS × 4 at 2 ohms or 700 watts RMS × 2 bridged at 4 ohms.
Does the amplifier include DSP?
Yes. It includes six DSP channels: four amplified channels and two processed pass-through outputs.
Does the NAV-TV interface include DSP?
No. The included ZEN-H is the non-DSP A2B interface. The Cicada amplifier performs the DSP processing.
Are the Road Glide tweeter grilles included?
Yes. The package includes a matched pair of 24CHDRGGTK-075 Road Glide grilles with RR075T tweeters.
How are the rear tweeters mounted?
The rear RR075T tweeters mount over the CM69.2X drivers with the included 24CHD69TB tweeter bridges.
Are saddlebag speaker mounts included?
Yes. The complete 24CHDLID 6×9 saddlebag lid cut-in mounting system is included.
Do the factory saddlebag lids need to be cut?
Yes. Both compatible factory lids require permanent cutting for the rear component system.
Is rear-speaker wiring included?
Yes. The 24HDRO plug-and-play rear-output harness is included.
Is the Road Glide amplifier rack included?
Yes. The package includes the 24HDAR-RG black-anodized aluminum amplifier rack and mounting hardware.
Is professional DSP tuning recommended?
Yes. The component crossovers, fairing acoustics, saddlebag locations and amplifier output make professional DSP setup strongly recommended.
Need Help Planning Your Road Glide Component System?
Garage Bagger Stereo can help verify Road Glide fitment, mid-bass and tweeter impedance selection, amplifier matching, fairing and saddlebag mounting, power and speaker wiring, passive crossover routing and factory A2B signal integration before installation.
