MMATS MBW690 6x9" Subwoofer — NOT FOR LIDS
The MMATS Pro Audio MBW690 is a single 6x9 subwoofer with a 2 inch copper voice coil, rated 300 watts RMS (500 watts program) on a single 4 ohm coil. It is not a drop-in replacement for a standard 6x9 speaker and does not fit standard Harley-Davidson speaker lids.
A true 6x9 subwoofer, not a lid speaker.
Rated 300 watts RMS with a 28 Hz-250 Hz response. Call before ordering to confirm mounting depth, enclosure space and amplifier power.
- 300 W RMS / 500 W program
- 2" copper voice coil, single 4 ohm
- 28 Hz - 250 Hz, 88 dB
Key Product Details
| Brand | MMATS Pro Audio |
| Model | MBW690 |
| Size | 6x9 subwoofer, single |
| Power handling | 500 W program / 300 W RMS |
| Voice coil | 2" copper wire, aluminum former, single 4 ohm |
| Order type | Special order, 20% restocking fee |
Planning Around the MBW690
With a 28 Hz - 250 Hz response, the MBW690 is a dedicated 6x9 subwoofer for bass, not a full-range lid speaker. This is a special order item and a 20% restocking fee applies. The single 4 ohm voice coil and 300 W RMS rating set the amplifier channel you need; confirm the enclosure and mounting space on your build before ordering.
Specifications
| Power handling | 500 Watts Program / 300 Watts RMS |
| Voice coil | 2" copper wire, aluminum former, single 4 ohm |
| Winding length | 1.25" |
| Magnet | 50 oz. Y-30 ferrite magnet / NEO blend |
| Mounting depth | 4.5" |
| Frequency response | 28 Hz - 250 Hz |
| Efficiency | 88 dB, 1 watt at 1 meter |
Thiele-Small Parameters
| Re (voice coil resistance) | 4 ohms |
| Sd (cone area) | 0.022596 m² |
| Vas | 7.031 L |
| Mms | 130 g |
| Fs (resonance) | 44.823 Hz |
| Qts | 0.399 |
| Xmax | 1.25" peak to peak |
Related Paths
MMATS MBW690 FAQ
Will the MBW690 fit my saddlebag lids?
No. It does not fit standard Harley-Davidson speaker lids and is not a drop-in speaker-lid replacement.
How much power does it handle?
500 watts program and 300 watts RMS.
Is it a single or dual voice coil?
A single 4 ohm voice coil, 2 inch copper wire on an aluminum former.
Is it returnable?
It is a special order item and a 20% restocking fee applies.
What should I check before ordering?
Fitment, mounting depth, enclosure space and amplifier power. Call 864-334-6131 if you are unsure.
Need Help Choosing?
Tell us your bike, model year and what you want to add, and we will confirm fitment and the right parts before you order.
Similar Products
6x9 Subwoofer vs 6x9 Speaker: Why the MBW690 Won't Go in Your Lids
Search "6x9 woofer" or "best 6x9 speakers for bass" and you'll find two different animals. A 6x9 lid speaker plays the full range from a stock lid opening. The MBW690 is a dedicated 6x9 subwoofer. MMATS rates it from 28 Hz to 250 Hz with 4.5" of mounting depth, and it does not fit standard Harley-Davidson speaker lids.
Want more bass out of the stock lid openings? Look at 6x9 mid-bass and component speakers built for lids, like the Cicada CXK69 component kit. Want real low end from a custom enclosure? That's the MBW690's job. Compare more in motorcycle subwoofers.
Powering a 6x9 Sub: Amp, Crossover and Enclosure
The MBW690 has a single 4 ohm voice coil rated 300 W RMS. Give it one amplifier channel that makes about that much at 4 ohms. Most builds use a mono amp, and a mono amp is never plug and play: it needs its own fused power run, ground, signal and a tune. Shop motorcycle amplifiers.
The sub tops out at 250 Hz, so cut it off with a low-pass filter on the amp or a motorcycle DSP and let the lid and fairing speakers handle the rest.
Plan the box before the sub. Mounting depth and enclosure space decide whether this works on your bike. Talk to us first.
More MMATS MBW690 6x9" Subwoofer — NOT FOR LIDS Questions
Can I run the MBW690 off my factory Harley radio?
No. It needs an amplifier channel rated for about 300 W RMS at 4 ohms. A mono amp is the usual choice, and a mono amp is never plug and play.
What 6x9 should I get for more bass in my stock saddlebag lids?
Use a 6x9 mid-bass or component speaker built for lid locations, such as the Cicada CXK69 kit. The MBW690 does not fit standard Harley-Davidson speaker lids.
Do I need a crossover with a 6x9 subwoofer?
Yes. MMATS rates the MBW690 to 250 Hz, so set a low-pass filter on the amp or in a DSP.
