Ground Zero GZHW-8SPL-D2 FLAT 8" Subwoofer
The Ground Zero GZHW-8SPL-D2 FLAT is an 8 inch shallow-mount SPL subwoofer with a mounting depth of just over 4 inches. It is sold individually.
A shallow 8 inch sub for tight enclosures
Cast aluminum basket, sandwich paper cone and a 2 in copper voice coil in a driver just over 4 inches deep.
- Mounting depth just over 4 inches
- Xmax 29 mm (1.14 in), Fs 31.5 Hz
- Vas 14.2 L (0.50 cu ft), Qts 0.41
Key Product Details
| Brand | Ground Zero |
| Size | 8 inch shallow-mount SPL subwoofer |
| Quantity | Sold individually |
| Mounting depth | Just over 4 inches |
| Voice coil | 2 in copper |
| Xmax | 29 mm (1.14 in) |
| Fs | 31.5 Hz |
| Qts | 0.41 |
Power and impedance figures are not part of this listing; ask us if you need them confirmed for your amplifier match.
Where the Flat 8 Inch Subwoofer Fits
The store lists small vented or sealed truck boxes, spare tire enclosures and some OEM-sized saddlebag and side-by-side enclosures as suitable uses. With a mounting depth of just over 4 inches and Vas of 14.2 L (0.50 cu ft), check your available depth and enclosure volume before building.
Specifications
| Cone | Klippel-optimized sandwich paper cone |
| Surround | U-shape rubber |
| Basket | Massive cast aluminum |
| Voice coil | 2 in copper |
| Terminal | Chrome-plated push terminal |
| Xmax | 29 mm (1.14 in) |
| Fs | 31.5 Hz |
| Vas | 14.2 L (0.50 cu ft) |
| Qts | 0.41 |
Related Paths
GZHW-8SPL-D2 FLAT FAQ
How deep is the GZHW-8SPL-D2 FLAT?
Its mounting depth is just over 4 inches, which is why it is described as shallow-mount.
Is it sold as a pair?
No. It is sold individually.
What enclosures does the store list for it?
Small vented or sealed truck boxes, spare tire enclosures and some OEM-sized saddlebag and side-by-side enclosures.
What are the key driver parameters?
Xmax is 29 mm (1.14 in), Fs is 31.5 Hz, Vas is 14.2 L (0.50 cu ft) and Qts is 0.41.
