Diamond Audio MS69NEO — 6x9 High Output Neo Midrange Speakers
The Diamond Audio MS69NEO is a premium 6x9 high-output neodymium midrange speaker set built for loud motorcycle, powersports and performance audio systems. With a waterproof DUPONT™ Kevlar cone, 350W RMS power handling and 96 dB sensitivity, it is designed to cut through wind, road noise and open-air riding conditions with strong, clear midrange output.
High-Output 6x9 Midrange
- 350W RMS / 700W max power handling
- 96 dB sensitivity
- 4Ω impedance
- Waterproof DUPONT™ Kevlar cone
- Neodymium motor, 2-inch high-temperature voice coil
- Cast aluminum basket
Key Specifications
| Model | MS69NEO |
| Speaker Size | 6x9 inch |
| Impedance | 4Ω |
| Power Handling | 350W RMS / 700W max |
| Sensitivity | 96 dB |
| Frequency Response | 90 Hz – 10 kHz |
| Cone | Waterproof DUPONT™ Kevlar |
| Motor | Neodymium |
| Voice Coil | 2 inch high-temperature voice coil |
| Diameter | 9.193" x 6.378" |
| Mounting Diameter | 8.583" x 5.748" |
| Mounting Depth | 3.091" |
Use clean amplifier power, correct filtering and proper installation hardware for best performance.
Why Riders Choose the MS69NEO
- High-output 6x9 performance for motorcycle, powersports and custom vehicle audio builds.
- 350W RMS / 700W max power handling for aggressive midrange output.
- 96 dB sensitivity helps produce strong volume with efficient amplifier power.
- Waterproof DUPONT™ Kevlar cone for durability in demanding environments.
- Neodymium motor and 2-inch high-temp voice coil for efficiency and control.
- Cast aluminum basket for strength and vibration resistance.
Best With
- Harley-Davidson and Indian bagger audio builds
- Saddlebag lids, custom 6x9 pods, doors and performance enclosures
- High-output 4Ω midrange systems
- Systems where vocals, guitars and mid-bass punch need to project clearly
Garage Bagger Stereo Advantage
- Motorcycle-specific speaker matching and install support
- Clean wiring, correct impedance planning and system layout help
- Setup guidance for loud, clear highway performance
- Nationwide shipping and tech support
Build the Rest of the System
Diamond Audio MS69NEO FAQ
Are these sold as a pair?
This Diamond Audio listing is for a speaker set/pair. Verify your install layout and quantity needed before ordering.
What are they best used for?
They are best used as high-output midrange speakers where projection and clarity matter more than low sub-bass output.
What impedance and power handling do they have?
The MS69NEO is a 4Ω speaker rated for 350W RMS and 700W maximum.
Need Help Choosing?
Talk to our team about matching the MS69NEO to your motorcycle, amplifier and install layout.
