Cicada Audio CHX69 6x9" Pro Coaxial Horn Speakers
The Cicada Audio CHX69 is the 6x9" pro coaxial horn speaker for Harley-Davidson bagger audio systems, sold as a pair in 2Ω (CHX69.2) or 4Ω (CHX69.4) so you can match the impedance of your amplifier channel. It is rated at 400 watts RMS / 800 watts max, with a 3.75" mounting depth and 8.5" mounting diameter for 6x9 speaker locations.
6x9 Pro Coax in 2Ω or 4Ω, Rated 400 Watts RMS
Pick the CHX69.2 or CHX69.4 to match your amplifier channel, then confirm your 6x9 speaker location has the 3.75" depth and 8.5" cutout it needs.
- 400 watts RMS / 800 watts max
- 92dB sensitivity, 75Hz–20kHz
- Available in 2Ω and 4Ω versions
Key Product Details
| Product | Cicada Audio CHX69 6x9" Pro Coaxial Horn Speakers |
| Part Numbers | CHX69.2 = 2Ω version / CHX69.4 = 4Ω version |
| Speaker Type | Pro coaxial horn speaker, 6x9" |
| Best For | Harley-Davidson bagger audio and amplified 6x9 speaker locations |
| Sold As | Pair |
| Warranty | 2 years |
Always verify impedance, speaker location, mounting depth, amplifier power, wiring, crossover setup, and final fitment before ordering for your Harley-Davidson audio build.
Built for Amplified Harley-Davidson Bagger Audio
The CHX69 is built for riders who want a serious upgrade over a basic replacement speaker. A horn-loaded compression driver gives it the projection and efficiency that amplified bagger systems need at highway speed.
Cicada pairs a 2.5" mid-bass voice coil with a 1.75" tweeter voice coil, with an external crossover and selectable tweeter attenuation.
- Carbon Matrix Composite cone.
- External 12dB vented, encased crossover.
- -3dB / -6dB tweeter attenuation through a heat-sink encased resistor.
Specifications
| Speaker Size | 6x9" pro coaxial horn driver |
| Impedance Options | CHX69.2 = 2Ω / CHX69.4 = 4Ω |
| Power Handling | 400 watts RMS / 800 watts max |
| Frequency Response | 75Hz–20kHz +/-3dB |
| Sensitivity | 92dB, 1W / 1M |
| Mid-Bass Voice Coil | 2.5" / 64mm |
| Tweeter Voice Coil | 1.75" / 44mm |
| Crossover | External 12dB at 4kHz, vented and encased |
| Tweeter Attenuation | -3dB / -6dB heat-sink encased resistor |
| Mounting Depth | 3.75" / 95mm |
| Mounting Diameter | 8.5" / 216mm |
Fitment and System Planning
Confirm speaker depth, mounting diameter, pod and grille clearance, wiring path, impedance and amplifier compatibility before installation.
Road Glide, Street Glide, CVO and custom bagger applications can need adapters, rings or pods depending on the year and layout. If you are unsure, confirm your year and model with Garage Bagger Stereo before ordering the CHX69.
What to Pair With the CHX69
These parts help you power, wire and tune the speakers correctly.
Cicada Motorcycle Amplifiers
Power the speakers with an amplifier built for Harley-Davidson audio.
Motorcycle DSP
Tune the system with a digital sound processor built for Harley-Davidson audio.
Cicada HDFLXFO Front Fairing Speaker Harness
Plug-and-play harness for front fairing speakers on 2014+ Harley-Davidson.
Speaker Installation Parts
Adapters, rings, grilles and mounting parts for speaker installs.
Related Cicada & Motorcycle Audio Paths
Build the system around the correct speaker, amplifier, DSP, wiring, and installation parts. These related collections help match the CHX69 with the right Harley audio upgrade path.
Best Use for the CHX69
Choose it when the goal is loud 6x9 output, strong vocal projection and clean highs from a bagger system with real amplifier power behind it.
Amplified System Recommended
These speakers are intended for serious motorcycle audio systems. For best results, match the CHX69 with proper amplifier power, correct impedance selection, clean wiring, and a real tuning plan.
Cicada CHX69 FAQ
What is the difference between the CHX69.2 and the CHX69.4?
The CHX69.2 is the 2Ω version and the CHX69.4 is the 4Ω version. Choose the impedance that matches your amplifier channel and wiring plan.
How much power can the CHX69 handle?
It is rated at 400 watts RMS and 800 watts max, and is intended for amplified Harley-Davidson audio systems.
What mounting size does the CHX69 need?
It has a mounting depth of 3.75" (95mm) and a mounting diameter of 8.5" (216mm). Verify the available depth and cutout in your speaker location before ordering.
Does the CHX69 come with a crossover?
Yes. It uses an external 12dB crossover with an optional -3dB / -6dB tweeter resistor so you can set the horn level.
Are the CHX69 speakers sold as a pair?
Yes. The CHX69 is sold as a pair.
What warranty does the CHX69 carry?
Cicada Audio products carry a two-year warranty.
What else do I need to run the CHX69?
Plan for an amplifier that matches the speaker impedance and power handling, OFC speaker wire, clean signal input, and a tuning plan such as a DSP. Garage Bagger Stereo can help you match the parts to your bike.
Does Garage Bagger Stereo install the CHX69?
Garage Bagger Stereo offers motorcycle audio installation at our Taylors, SC shop and can help you plan a DIY install. Start a Build Consultation or call 864-334-6131 to check scheduling.
Need Help Choosing?
Tell us your bike, model year and what you want to add, and we will confirm fitment and the right parts before you order.
