Cicada Audio 24FLXCXX-4X2SG 500W 2-Speaker Audio System
The Cicada Audio 24FLXCXX-4X2SG is a complete front-fairing audio package for compatible 2024 and newer Harley-Davidson Street Glide motorcycles. It combines a compact four-channel amplifier, two high-efficiency 2-ohm Pro Coaxial speakers, factory A2B radio integration, Street Glide-specific mounting hardware and a rear-output harness for future system expansion.
Front Audio with Rear Expansion Support
- Designed for compatible 2024+ Street Glide motorcycles
- FLX500.4 compact four-channel Class-D amplifier
- 125 watts RMS × 4 channels at 2Ω
- Two CXX65.2 6.5-inch Pro Coaxial speakers
- Both included speakers are 2Ω
- Street Glide fairing grilles included
- NAV-TV ZEN-H A2B factory-radio integration
- Street Glide amplifier rack included
- 8-AWG amplifier power kit included
- Rear-output harness included for future expansion
24FLXCXX-4X2SG Complete System Overview
This Cicada Audio package upgrades the two factory Street Glide fairing speaker locations while installing the four-channel amplifier, power wiring, A2B interface and output wiring needed for a larger system.
One pair of CXX65.2 6.5-inch Pro Coaxial speakers installs behind the included Cicada-branded Street Glide fairing grilles. Each speaker has a nominal impedance of 2 ohms and connects to its own amplifier channel.
The FLX500.4 provides four amplified channels. The supplied configuration uses two channels for the front speaker pair, while the included 24HDRO harness prepares the other two channels for a separately purchased rear-speaker upgrade.
Standard Non-DSP System Configuration
FLX500.4 Power Amplifier
This package uses the standard FLX500.4 four-channel amplifier. It delivers compact Class-D power but does not include an integrated digital signal processor.
NAV-TV ZEN-H A2B Integration
The included ZEN-H interface extracts the factory digital A2B audio signal and connects it directly to the Cicada amplifier through the included vehicle-specific harness.
Speaker Impedance and Amplifier Channel Load
Front Left: 2Ω
One CXX65.2 speaker connects to the assigned left-front amplifier channel and presents a nominal 2-ohm load.
Front Right: 2Ω
The second CXX65.2 speaker connects to the assigned right-front amplifier channel and presents a nominal 2-ohm load.
Rear Channels: Available
No rear speakers are included. The remaining two amplifier channels can power a properly matched future rear-speaker system.
Everything Included in the Complete System
FLX500.4 — Four-Channel Amplifier
One compact Class-D amplifier rated for 125 watts RMS × 4 channels at 2 ohms, 95 watts RMS × 4 at 4 ohms or 250 watts RMS × 2 bridged at 4 ohms.
CXX65.2 — 6.5" Pro Coaxial Speakers
One pair of 2-ohm CXX65.2 speakers for the Street Glide fairing. Each speaker is rated for 100 watts RMS and uses a Kevlar cone, integrated PEI tweeter and built-in 6dB crossover.
24CHDSGG — Street Glide Fairing Grilles
One pair of Cicada Audio-branded aluminum fairing grilles designed specifically for compatible 2024 and newer Street Glide motorcycles.
24HDAR-SG — Street Glide Amplifier Rack
Black-anodized aluminum amplifier rack that uses compatible factory amplifier mounting locations and includes predrilled FLX mounting points and installation hardware.
HDPG8K — 8-AWG Amplifier Power Kit
Includes six-foot power and ground cables with black braided covering, battery-side ring terminals, amplifier-side ferrules, remote trigger wiring, a waterproof Mini-ANL fuse holder and 60-, 80- and 100-amp fuses.
24HDZENHCAKIT — NAV-TV ZEN-H A2B Interface
NAV-TV ZEN-H factory A2B interface with a Cicada Audio direct-connect amplifier harness and correctly pinned, positive-locking Molex connections.
24HDRO — Rear Output Speaker Harness
Plug-and-play rear-output harness with factory-style connectors, two short extensions and two longer speaker-wire leads for future rear-speaker installation.
FLX500.4 Amplifier Power
125W × 4 at 2Ω
The amplifier produces up to 125 watts RMS on each of its four channels when operating at 2 ohms and 14.4 volts.
95W × 4 at 4Ω
The amplifier also supports four-channel operation with compatible 4-ohm speakers.
250W × 2 Bridged
The published bridged configuration is 250 watts RMS × 2 into compatible 4-ohm loads.
Wide Input Range
The 0.2V–12V gain range supports compatible factory-radio interfaces, aftermarket radios and external signal processors.
Flexible Crossovers
Selectable LPF, FULL and HPF modes provide 20Hz–20kHz adjustment with selectable 6, 12, 24 or 48dB-per-octave slopes.
Compact Motorcycle Chassis
The small aluminum chassis installs on the included Street Glide amplifier rack without consuming unnecessary fairing space.
FLX500.4 Amplifier Specifications
CXX65.2 Street Glide Fairing Speakers
Rear-Speaker-Ready System Design
The FLX500.4 provides four amplifier channels, but the supplied system includes only the two front fairing speakers. Cicada includes the 24HDRO harness so a compatible rear-speaker pair can be added without replacing the amplifier or rebuilding the factory-radio interface.
Included for Expansion
- Two additional amplifier channels
- 24HDRO rear-output harness
- Factory-style harness connections
- Long speaker-wire leads for saddlebag routing
Not Included
- Rear saddlebag speakers
- Saddlebag speaker adapters
- Cut-in speaker-lid hardware
- Rear speaker grilles or pods
Factory A2B Radio Integration
The NAV-TV ZEN-H interface extracts the factory digital A2B audio signal. The included Cicada harness routes that signal directly into the FLX500.4 through correctly pinned Molex connections.
- Designed for compatible 2024+ Harley-Davidson A2B systems
- No cutting or splicing of the factory signal harness
- Positive-locking automotive-grade connections
- Direct integration with compatible Cicada Audio amplifiers
- Compact routing inside the Street Glide fairing
- Standard non-DSP system configuration
Installation and System Setup
- Mount the amplifier securely on the included 24HDAR-SG rack.
- Use the included HDPG8K power and ground wiring kit.
- Use a correctly rated fuse installed near the battery connection.
- Use the included A2B interface and Cicada amplifier harness.
- Confirm speaker mounting depth and grille clearance before assembly.
- Set the amplifier high-pass filters for the CXX65.2 speakers.
- Set amplifier gain using clean measured output.
- Do not exceed the 100-watt RMS rating of the front speakers.
- Secure all wiring against vibration, heat and sharp edges.
- Professional installation and system setup are recommended.
Complete System Specifications
Fitment and Ordering Notes
- Designed for compatible 2024 and newer Street Glide motorcycles.
- The package includes two 2-ohm front speakers.
- The package does not include selectable speaker impedance options.
- Two amplifier channels power the included front speaker pair.
- The remaining two channels are available for future expansion.
- The rear-output harness is included.
- Rear speakers and saddlebag mounting components are not included.
- No saddlebag cutting is required for the supplied front-only system.
- Future rear installation requirements depend on the selected mounting system.
- The amplifier does not include built-in DSP.
- Professional installation and system setup are recommended.
Best For
- Compatible 2024+ Street Glide front-speaker upgrades
- Riders starting with a two-speaker amplified system
- Factory A2B radios requiring aftermarket amplifier integration
- Efficient 2-ohm Pro Coaxial motorcycle speakers
- Systems using a compact standard four-channel amplifier
- Riders planning to add compatible rear speakers later
- Professional Street Glide audio installations
Related Motorcycle Audio Categories
Cicada and 2024+ Harley Audio
System Support
Cicada 24FLXCXX-4X2SG FAQ
What impedance are the included speakers?
Both included CXX65.2 speakers have a nominal impedance of 2 ohms.
How many speakers are included?
The system includes two 6.5-inch CXX65.2 Pro Coaxial speakers for the Street Glide fairing.
What load does the amplifier see?
Each included speaker connects to its own amplifier channel, so each loaded front channel operates at a nominal 2-ohm load.
Are all four amplifier channels used?
No. The supplied system uses two channels for the front speakers. The remaining two channels are available for a compatible rear-speaker upgrade.
How much power does the amplifier produce?
The FLX500.4 produces 125 watts RMS × 4 at 2 ohms, 95 watts RMS × 4 at 4 ohms or 250 watts RMS × 2 bridged at 4 ohms.
How much power can the speakers handle?
Each CXX65.2 speaker is rated for 100 watts RMS and 200 watts maximum. Amplifier gain must be set correctly to protect the speakers.
Does the amplifier include a DSP?
No. The FLX500.4 is a standard four-channel amplifier without an integrated digital signal processor.
Does the system integrate with the factory A2B radio?
Yes. The package includes a NAV-TV ZEN-H A2B interface and Cicada Audio direct-connect amplifier harness.
Are Street Glide fairing grilles included?
Yes. The package includes the Cicada Audio 24CHDSGG aluminum fairing grille pair.
Is the amplifier rack included?
Yes. The package includes the 24HDAR-SG Street Glide amplifier rack and its mounting hardware.
Is rear-speaker wiring included?
Yes. The 24HDRO rear-output harness is included for a future rear-speaker upgrade.
Are rear speakers included?
No. Rear speakers and the required saddlebag mounting components must be purchased separately.
Do the saddlebags need to be cut for this system?
No saddlebag modification is required for the supplied front-only system. A future rear-speaker installation may require cutting or other modification depending on the selected mounting solution.
