2023.5+ Harley-Davidson 2-Speaker Plug and Play Audio System | DS18
PRODUCT INFORMATION
2023.5+ Harley-Davidson 2-Speaker Plug and Play Audio System | DS18
Choose Your Motorcycle:
$1,400.74
Couldn't load pickup availability
Additional Payment Info
2023.5+ Harley-Davidson 2-Speaker Plug and Play Audio System | DS18
Need Help?
Call us at (864) 334‑6131 or message our team with your bike year/model and current upgrades. We'll map the best path to louder, cleaner sound.
-
Description
-
Reviews
2023.5+ Harley-Davidson 2-Speaker Plug-and-Play Audio System | DS18
Upgrade a compatible 2023.5 and newer Harley-Davidson Road Glide or Street Glide with a complete two-speaker audio system built around a DS18 four-channel amplifier, two high-output hybrid fairing speakers, NAV-TV factory A2B integration and the primary power and installation components required for the system.
Select Road Glide or Street Glide before ordering so the correct motorcycle configuration can be supplied. Two amplifier channels power the included front speakers, while two channels remain available for a properly matched future rear-speaker upgrade.
Complete Two-Speaker Audio System
- Road Glide and Street Glide options
- Designed for compatible late-model Harley A2B systems
- DS18 ION1600.4D four-channel Class-D amplifier
- 240 watts RMS Ă— 4 channels at 4 ohms
- Two DS18 PRO-HY6.4MSL 6.5-inch hybrid speakers
- 150 watts RMS per included speaker
- 4-ohm nominal impedance per speaker
- Built-in 1-inch titanium compression drivers
- NAV-TV ZEN-H A2B factory-radio integration
- 4-AWG amplifier power wiring
- Half-inch speaker spacers included
- Two amplifier channels available for expansion
Complete 2-Speaker Plug-and-Play System Overview
This Garage Bagger Stereo package combines the amplifier, two front fairing speakers, factory A2B signal interface, amplifier power wiring and speaker-spacing components required to build a high-output two-speaker audio system in a compatible late-model Harley-Davidson Road Glide or Street Glide.
The included DS18 PRO-HY6.4MSL speakers combine a shallow 6.5-inch midrange driver with a built-in 1-inch titanium compression driver. This hybrid design produces both midrange and high-frequency output from each fairing speaker location.
The DS18 ION1600.4D supplies four full-range amplifier channels. Two channels operate the included front speakers. The remaining channels can support a properly matched rear-speaker pair after the required speakers, wiring, mounting components and amplifier setup are added.
Road Glide and Street Glide Fitment
Road Glide Option
Select Road Glide for a compatible late-model sharknose-fairing motorcycle using the factory Harley-Davidson A2B audio platform.
- Road Glide fairing configuration
- Two front fairing speakers
- Half-inch speaker spacers
- NAV-TV A2B integration
Street Glide Option
Select Street Glide for a compatible late-model batwing-fairing motorcycle using the factory Harley-Davidson A2B audio platform.
- Street Glide fairing configuration
- Two front fairing speakers
- Half-inch speaker spacers
- NAV-TV A2B integration
Current Plug-and-Play Kit Lead Time
The current listed fulfillment time for this plug-and-play system is approximately 5–10 business days. Build time may vary with component availability and motorcycle configuration.
Everything Included in the Audio System
DS18 ION1600.4D Amplifier
One compact four-channel full-range Class-D amplifier rated for 240 watts RMS Ă— 4 at 4 ohms, 400 watts RMS Ă— 4 at 2 ohms and 800 watts RMS Ă— 2 bridged at 4 ohms.
Two DS18 PRO-HY6.4MSL Speakers
One pair of 6.5-inch shallow hybrid speakers with 4-ohm impedance, 150-watt RMS power handling and built-in 1-inch titanium compression drivers.
NAV-TV ZEN-H A2B Interface
One factory A2B interface that converts the compatible Harley radio signal into eight channels of 5-volt analog RCA output for aftermarket amplifier integration.
4-AWG Amplifier Power Kit
Heavy-gauge power and ground wiring with the primary connections and protection hardware required for the amplifier installation.
Half-Inch Speaker Spacers
Speaker-spacing components provide additional mounting clearance for the DS18 hybrid speakers in the applicable front fairing locations.
Road Glide or Street Glide Configuration
The selected Shopify variant identifies which motorcycle and fairing configuration the system is being prepared for.
Speaker Impedance and Amplifier Channel Configuration
Front-Left Speaker
One PRO-HY6.4MSL speaker presents a nominal 4-ohm load to its dedicated ION1600.4D amplifier channel.
Front-Right Speaker
The second PRO-HY6.4MSL speaker presents a nominal 4-ohm load to its dedicated amplifier channel.
Two Available Channels
Two amplifier channels remain available for a compatible future rear-speaker pair after the required mounting and wiring components are installed.
DS18 ION1600.4D Four-Channel Amplifier
The ION1600.4D is a compact full-range Class-D amplifier that delivers substantial output from a motorcycle-friendly chassis. High-level and RCA inputs, variable crossovers, protection circuits and a clipping indicator support flexible system integration and measured setup.
240W × 4 at 4Ω
Published four-channel output for compatible 4-ohm speaker systems.
400W × 4 at 2Ω
Available for separately designed compatible 2-ohm speaker systems.
800W Ă— 2 Bridged
Published bridged output into properly configured 4-ohm loads.
Adjustable Crossovers
Low-pass, high-pass and full-range modes support system-specific frequency control.
Clip Indicator
Power, protection and clipping indicators assist with safe amplifier setup.
Compact Chassis
The small amplifier footprint helps conserve installation space on a motorcycle.
DS18 PRO-HY6.4MSL Hybrid Fairing Speakers
Each PRO-HY6.4MSL combines a shallow 6.5-inch midrange loudspeaker with a built-in 1-inch titanium compression driver. This two-way hybrid arrangement provides both midrange projection and high-frequency output from one speaker assembly.
150W RMS
Each included speaker is rated for 150 watts RMS and 300 watts maximum.
4-Ohm Impedance
Each speaker presents a nominal 4-ohm load to its dedicated amplifier channel.
Hybrid Two-Way Design
A built-in titanium compression driver supplies high-frequency output without a separate tweeter location.
Shallow Mounting Depth
The 2.82-inch mounting depth supports tight motorcycle fairing installations.
IP65 Rated
Water-resistant construction and a protected grille support powersports use.
140Hz High-Pass Reference
DS18 publishes 140Hz as the recommended high-pass crossover reference.
NAV-TV ZEN-H Factory A2B Integration
The NAV-TV ZEN-H converts the compatible factory Harley-Davidson A2B radio signal into eight channels of analog RCA output for the DS18 amplifier and future system expansion.
Eight Analog Outputs
Supplies eight channels of low-level analog RCA output at up to 5 volts RMS.
Factory Control Retention
Retains compatible factory volume, balance, fader and radio EQ functions.
Direct A2B Integration
Interfaces directly with the compatible factory A2B data and audio system.
- Designed for compatible late-model Harley A2B audio systems
- Eight-channel analog RCA output
- Up to 5-volt RMS output
- Factory volume retention
- Factory balance and fader retention
- Factory EQ preset retention where supported
- No replacement aftermarket radio required
Power Wiring and Speaker Installation
4-AWG Amplifier Wiring
The included power kit supplies the heavy-gauge power and ground foundation required for the ION1600.4D amplifier.
Half-Inch Speaker Spacers
The supplied spacers provide additional fairing clearance for the shallow hybrid speakers.
- Disconnect the motorcycle battery before installation.
- Mount the amplifier securely with adequate ventilation.
- Install appropriate fuse protection close to the battery.
- Protect wiring from steering movement, heat and sharp edges.
- Use clean and secure battery and chassis connections.
- Confirm speaker depth and spacer clearance before assembly.
- Verify speaker polarity before reinstalling the fairing.
- Inspect battery and charging-system condition before high-output use.
Gain and Crossover Setup
Proper setup is critical because the ION1600.4D can produce more continuous power at 4 ohms than each included PRO-HY6.4MSL is rated to handle.
- Connect one front speaker to each of two amplifier channels.
- Do not bridge the amplifier channels for the included speakers.
- Configure the active channels for high-pass operation.
- Use 140Hz as the manufacturer’s published high-pass reference.
- Adjust the final crossover for the fairing and desired output.
- Set gain using measured clean output rather than by ear.
- Do not use amplifier gain as a volume control.
- Monitor the clipping indicator during setup.
- Reduce output immediately if distortion or mechanical noise occurs.
Future Rear-Speaker Expansion
Two unused amplifier channels and additional NAV-TV RCA outputs provide a path for a future rear-speaker upgrade. Rear expansion must be designed around compatible speaker impedance, RMS power handling, mounting depth, wiring and crossover requirements.
Already Available
- Two unused amplifier channels
- Additional NAV-TV RCA outputs
- Four-channel amplifier crossover controls
- 4-AWG amplifier power foundation
Required for Expansion
- Compatible rear speakers
- Saddlebag lids, adapters or speaker pods
- Rear-speaker wiring and connectors
- Correct impedance and RMS-power matching
- Final crossover and gain setup
Complete System Specifications
Fitment and Ordering Notes
- Select Road Glide or Street Glide before adding the kit to the cart.
- The package includes two front fairing speakers.
- Each included speaker has a nominal 4-ohm impedance.
- Two amplifier channels remain available for future expansion.
- The package uses NAV-TV factory A2B integration.
- The amplifier does not include built-in DSP.
- Half-inch speaker spacers are included.
- Additional fairing modification may still be required.
- Correct gain and high-pass crossover setup are required.
- Rear speakers and rear mounting components are not included.
- Professional installation and system setup are recommended.
Best For
- Compatible 2023.5+ Harley-Davidson audio upgrades
- 2024+ Road Glide front-speaker upgrades
- 2024+ Street Glide front-speaker upgrades
- Factory Skyline radio and A2B audio integration
- High-output two-speaker fairing systems
- Riders planning to add saddlebag speakers later
- Professional motorcycle audio installations
Related Motorcycle Audio Categories
2023.5+ Harley Audio
Signal and Amplifier Support
2023.5+ Harley 2-Speaker Audio System FAQ
How many speakers are included?
The system includes two DS18 PRO-HY6.4MSL 6.5-inch hybrid speakers for the front fairing.
What impedance are the included speakers?
Each included speaker has a nominal impedance of 4 ohms.
How much power can each speaker handle?
Each PRO-HY6.4MSL is rated for 150 watts RMS and 300 watts maximum.
How much power does the amplifier produce at 4 ohms?
The ION1600.4D produces up to 240 watts RMS on each of its four channels at 4 ohms.
Is the amplifier too powerful for the speakers?
The amplifier can produce more continuous power than each speaker is rated to handle. It can be used safely when gain, high-pass crossover and maximum clean output are configured correctly.
Are all four amplifier channels used?
No. Two channels power the supplied speakers. Two channels remain available for a compatible future rear-speaker pair.
What does the NAV-TV ZEN-H do?
It converts the compatible factory Harley A2B signal into analog RCA outputs that can be connected to the aftermarket amplifier.
Does the NAV-TV interface retain factory controls?
It retains compatible factory volume, balance, fader and supported EQ functions while integrating the aftermarket amplifier.
Does this package include DSP?
No. The standard ZEN-H interface and ION1600.4D amplifier do not provide advanced system DSP. A compatible external processor can be added when equalization, time alignment or output limiting is needed.
Are the speakers weather resistant?
Yes. The speakers are IP65 rated and use water-resistant cones and protective grille cloth. They should not be described as submersible.
Can rear speakers be added later?
Yes. The two unused amplifier channels can power a properly matched rear-speaker pair after the required speakers, wiring, mounting hardware and system setup are added.
Are speaker spacers included?
Yes. The package includes half-inch spacers to provide additional fairing speaker clearance.
Will the speakers fit without modification?
Fitment depends on the motorcycle and factory speaker enclosure. Additional spacing, pod modification or clearance work may still be required.
Are saddlebag speakers included?
No. This is a two-speaker system. Rear speakers, saddlebag mounting parts and rear-speaker wiring must be purchased separately.
How long does the kit take to fulfill?
The current listed lead time is approximately 5–10 business days, subject to component availability and motorcycle configuration.
Need Help Matching This 2023.5+ Harley Audio System?
Garage Bagger Stereo can help verify Road Glide or Street Glide fitment, speaker impedance selection, amplifier matching, speaker and amplifier mounting, power and speaker wiring, and factory A2B signal integration before installation.
